產品型號：BDD系列 原產地：臺灣 品牌：TPC 產品說明： 1.檢出方式：限定距離反射 2.感應距離：2，3，5 cm 3.輸出方式：NPN NO/NC 4.工作電壓：DC10-30V 5.電線材質：PVC耐油電線 6.保護等級：IP66 7.防水性佳
型號 | 工作電壓 | 感應距離 | 應差距離 | 輸出方式 | 消耗電流 | 負載電流 | 殘留電壓 | 反應頻率 | 重量 |
Type | Power Supply | Sensing Distance | Differential Travel | Output | Current Consumption | Load Current | Voltage Drop | Response Frequency | Wieght |
BDD-02N | 10-30V DC | 2cm | ±10% | NPN NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. | Approx:92g |
BDD-02P | 10-30V DC | 2cm | ±10% | PNP NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. | |
BDD-03N | 10-30V DC | 3 cm | ±10% | NPN NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. | |
BDD-03P | 10-30V DC | 3 cm | ±10% | PNP NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. | |
BDD-05N | 10-30V DC | 5 cm | ±10% | NPN NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. | |
BDD-05P | 10-30V DC | 5 cm | ±10% | PNP NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. |
